Description
- Insulated steel tank with stainless steel cover
- 1-1/2″ NPT platen water inlet (from press outlet manifold)
- 2″ NPT steam vent connection
- 3/4″ NPT cold water inlet with:
- Solenoid valve (115/1/60 supply voltage)
- Ball valve water shutoff
- Internal spray nozzle
- 1-1/4″ primary drain line
- 1/2” NPT tank drain (cleanout)
- (4) leveling screws
- Dimensions: 24″ L-R x 24″ F-B x 56″ H
- 110 Volt
- Water requirements: 3 GPM (approx.) @ 50 psi and 70 degrees F
