Laboratory Press Parts and Accessories for Carver Presses
Digital and Analog Gauges, Two-Gauge Manifold, Digital Force Verification Kit, and Dial Face Thermometers
No. 6306 Digital Gauges – Digital force gauges for Standard Manual 2 & 4 Post and 12 ton Pellet Presses in your choice of 100 or 10 pound increments. Easy to read LCD Round Gauge Face, Battery Powered, Stem Mounted for 2 & 4 Post Manual Press Models, and Back Mounted for 12 ton Manual Pellet Press Models. Approximate accuracy is +/-1% of reading starting at 1,000 lbs up to maximum tonnage of press (12, 25 or 30 tons).
Calibration Service
Carver offers a calibration service on new and existing gauges. For new gauges the part number is 1525.00001. For existing gauges; please feel free to contact our Service Department at 260-233-6900 or wabashservice@acscorporate.com for details.
Reference Table
| Digital Gauges –Standard Manual and 12 ton manual pellet press Model 4350 Series (Digital gauges are setup to read in pounds force. Also available in kilo gram, kilo newton, US tons, and metric tons per request) | |
|---|---|
| Part # | Description |
| 6306.BN23 | Digital Gauge for Standard 12 ton Manual Presses, 0-24,000 lb, Reading in 100 lb increments |
| 6306.BN22 | Digital Gauge for Standard 12 ton Manual Presses, 0-24,000 lb, Reading in 10 lb increments |
| 6306.BN33 | Digital Gauge for Standard 25 ton Manual Presses, 0-50,000 lb, Reading in 100 lb increments |
| 6306.BN32 | Digital Gauge for Standard 25 ton Manual Presses, 0-50,000 lb, Reading in 10 lb increments |
| 6306.BN43 | Digital Gauge for Standard 30 ton Manual Presses, 0-60,000 lb, Reading in 100 lb increments |
| 6306.BN42 | Digital Gauge for Standard 30 ton Manual Presses, 0-60,000 lb, Reading in 10 lb increments |
| 6306.PN23 | Digital Gauge for Standard 12 ton Manual Pellet Presses Only, 0-24,000 lb, Reading in 100 lb increments |
| 6306.PN22 | Digital Gauge for Standard 12 ton Manual Pellet Presses Only, 0-24,000 lb, Reading in 10 lb increments |
| *NOTE: All Digital Gauges are configured to the press that they are to be installed on. Please provide Model and Serial Number for verification at the time of order processing. | |
| Analog Gauges (Read in pounds force and metric tons) – Analog Gauges for 12 ton Models, Model C and Mini C Manual Presses | |
| 381005 | Model B/C gauge, 0-24,000 lb. applied force, 11,000 kg, 200 lb. increments (Normally furnished on standard 12 ton presses) |
| 381042 | Model B/C gauge, 0 – 500 lb., 250 kg, 5 lb. increments |
| 381001 | Model B/C gauge, 0 – 1,000 lb., 450 kg, 10 lb. increments |
| 381002 | Model B/C gauge, 0 – 2,000 lb., 900 kg, 20 lb. increments |
| 381003 | Model B/C gauge, 0 – 5,000 lb., 2,250 kg, 50 lb. increments |
| 381004 | Model B/C gauge, 0 – 10,000 lb., 4,500 kg, 100 lb. increments |
| Analog Gauges for 25 ton Models and Model M Manual Presses | |
| 381008 | Model K/M gauge, 0 – 50,000 lb. applied force, 22,500 kg, 500 lb. increments (Normally furnished on standard 25 ton presses) |
| 381006 | Model K/M gauge, 0 – 5,000 lb., 2,250 kg, 50 lb. increments |
| 381007 | Model K/M gauge, 0 – 10,000 lb., 4,500 kg, 100 lb. increments |
| 381176A | Model K/M gauge, 0 – 1,000 lb., 450 kg, 10 lb. increments |
| Analog Gauges for 30 ton Manual Presses | |
| 381072 | Model K/M gauge, 0 – 60,000 lb., 27,250 kg, 500 lb. increments (Normally furnished on standard 30 ton presses) |
| 381201 | Model K/M gauge, 0 – 10,000 lb., 4,500 kg, 100 lb. increments |
| 381225 | Model K/M gauge, 0 – 5,000 lb., 2,250 kg, 50 lb. increments |
| Dial Face Thermometers for Thermostatically Controlled Platens | |
| 385001 | Dial face thermometer 150°F to 750°F |
| 385019 | Dial face thermometer 50°C to 400°C |
No. 2096CE & 2096-1CE Two Gauge Manifolds– The 2096CE is for most standard manual presses, except the Mini C. The 2096-1CE is specifically designed for the Mini C Model Press only. These manifolds permit mounting of both high (right) and low (left) range gauges for more precise application of pressure. Hand operated shut-off valve protects low pressure gauge when using high pressure.
Gauges sold separately
No. 5177 Digital Force Verification Kit
Allows customers to perform their own force verification or calibration on their press gauges or force monitoring systems. This kit is designed for use with most Carver presses and includes calibration documents by instruments traceable to NIST. This kit reads full scale in 100 lb increments with a digital readout up to 50 tons (100,000 lbs.). Click here for details.
Laboratory Press Parts and Accessories for Carver Hydraulic Presses
Repair Kits and Hydraulic Units
No. 3729 12 Ton Hydraulic Repair Kit (gray only)
No. 3730 25 Ton Hydraulic Repair Kit (gray only)
No. 3789 30 Ton Hydraulic Repair Kit for pump and reservoir
Repair parts for Carver hydraulic units contain hydraulic oil, seals, gaskets, pins, fittings, valve parts and instructions needed to rebuild the unit.
Please Note: Carver repair kits include all wear components that are replaceable for the 12 & 25 ton (current gray only) and 30 ton. In most cases replacing these components will solve hydraulic unit issues. In units with excessive wear or damage to cylinders, rods, permanent valve seats, etc., the repair kit may not be 100% effective. Carver repair kits are a non-refundable item.
Reference Table
| Part# | Description |
|---|---|
| 3912 | 12 ton hydraulic unit, for most standard 12 ton presses* |
| 3912.P | 12 ton hydraulic unit for 4350 series pellet presses |
| 3925 | 25 ton hydraulic unit, for most standard 25 ton presses* |
| 321007 | Pump and reservoir for most standard 30 ton manual presses |
| 3467-0 | Hydraulic cylinder for most standard 30 ton manual presses and 25/30 ton Auto Presses (serial number specific – Consult factory for details) |
| 3729 | 12 ton repair kit, for gray units only |
| 3730 | 25 ton repair kit, for gray units only |
| 319002 | Pump Assembly for 12 & 25 ton manual hydraulic unit/jack (S-Z) |
| 3789 | 30 ton repair kit for pump and reservoir |
| 3867 | 30 ton repair kit for 2-bolt hole pattern 3467-0 cylinders on Manual presses |
| 6315.5 | 30 ton repair kit for Auto presses with 25/30 cylinder 3467-0 |
| 2170 | Hydraulic fluid/oil (pint size) |
| *Note: Carver current hydraulic setup is with 1/8” fittings and tubing. If you have the older style 5/8” tubing, we would recommend the purchase of our current 1/8” fitting (965182) and tubing (367149) when purchasing a new hydraulic unit/jack. One fitting comes with the purchase of a new jack. | |
