Systech 8101e OxySense
Oxygen Transmission Rate Analyzer
Better resolution. Proven reliability. Calibration-free measurement. Trusted by Nestlé R&D Centre and proven by suppliers like Uflex Jammu, with deployments supporting programs for Reliance, ITC, and many more (references available on request).
Ultra-wide range: 0.05 to 432,000 cc/m²/day covers everything from ultra-high barrier films (metallized, AlOx) to breathable packaging, so you can qualify the full spectrum from excellent barrier to poor barrier on one platform.
Testing Packaging for Products You Trust Daily
From Maggi Masala Magic and ITC Tepley Green Tea to snacks, pharma packs, and many more products, brands rely on oxygen barrier testing to protect freshness and shelf life.
Industry Leaders Trust Our Precision
From Fortune 500 companies to innovative startups, powering quality control globally
Choose the Right Sensor for Your OTR Application
The eMetric™ high sensitivity, wide range coulometric sensor meets ASTM D3985 and provides a range from 0.05 to 432,000 cc/(m²·day).
Coulometric Sensors (Faraday’s Law)
- Perform according to Faraday’s Law to measure oxygen transmission
- Analyze 100% of the oxygen passing through the sensor
- Provide unequivocal confirmation of ASTM D3985 conformance
- Support both films and packages testing methods
eMetric™ High Sensitivity Wide Range Sensor
- Range from 0.05 to 432,000 cc/(m²·day)
- Easy testing. Load the film and press a button to start
- Automatic relative humidity and temperature control
- TCM™ lets you test up to ten temperature/RH conditions
- Expandable up to 32 cells
How the Coulometric Sensor Works
Understanding the high-sensitivity eMetric™ detection process
Sample Isolation
The test film or package is clamped in the diffusion cell. Oxygen flows on one side, while a nitrogen carrier gas flows on the other.
Oxygen Permeation
Oxygen molecules permeate through the barrier material into the nitrogen carrier gas stream, which transports them to the sensor.
Coulometric Detection
The sensor detects Oxygen via an electrochemical reaction (Faraday's Law), generating a current directly proportional to the OTR.
See the 8101e OxySense® in Action
Watch how the 8101e delivers precise OTR measurement with eMetric™ coulometric sensor technology.
Advanced OTR Testing Made Simple
The 8101e OxySense® combines precision measurement with user-friendly operation for fast, reliable oxygen barrier testing.
eMetric™ Coulometric Sensor
High sensitivity, wide range eMetric™ coulometric sensor for ASTM D3985 compliant OTR testing.
Large Touch Screen
Large touch screen providing easy operation and display of results on a Windows® platform.
Q-Seal™ Cell Closure
Film loading made simple and effective with the Q-Seal™ gas free cell closure system.
Test Condition Matrix
TCM™ enables you, with the touch of a single button, to test a sample at up to ten different conditions of temperature and relative humidity.
Expandable Up to 32 Cells
Scale throughput as needs grow with expandable up to 32 cells for parallel testing.
Auto-Stop™ Protection
Prevents sensor damage due to excessive levels of oxygen. This feature extends sensor life.
Intelligent Software Features
Powerful Windows-based software with advanced data management, real-time visualization, and optional 21 CFR Part 11 compliance for pharmaceutical applications.
Real-Time Data Graphing
Live visualization of test data with dynamic graphs showing OTR trends as tests progress.
Auto-Stop™ Sensor Protection
Prevents sensor damage due to excessive levels of oxygen, extending sensor life and improving uptime.
Data Management
Complete data tracking, searching, sorting, and secure storage for comprehensive record keeping.
Easy Parameter Recall
Simple parameter input and instant recall of saved test configurations for faster setup.
21 CFR Part 11 Ready
Optional FDA-compliant software package available for pharmaceutical and regulated industries.
Complete System Diagnostics
Built-in diagnostic tools for system health monitoring and troubleshooting assistance.
Full Specifications
Comprehensive measurement capabilities for films and complete packages with ASTM/ISO compliance.
| Specification | Value | What This Means |
|---|---|---|
| Product Information | ||
| Model | 8101e OxySense® | Systech Illinois OTR Analyzer |
| Applications | Oxygen Transmission Rate (OTR) Testing, Barrier Films, Packaging, R&D, Quality Control | Primary OTR testing applications |
| Materials | Plastic Films, Foils, Laminates, Coated Papers, Flexible Packaging, Rigid Containers | Compatible sample materials |
| E-Metric Unmasked Range | ||
| Range (cc/(m²·day)) | 0.05 to 432,000 | Ultra-high to ultra-low barrier films |
| Range (cc/(100in²·day)) | 0.003 to 28,000 | Alternate units for ASTM-style reporting |
| Range (cc/(pkg·day)) | 0.00025 to 2000 | Typical reporting for complete packages |
| Resolution | 0.0001 cc/(m²·day) | Detects minute barrier differences |
| Repeatability cc/(m²·day) | ||
| Test Conditions | ||
| Test Temperature Range | 10°C to 40°C ± 0.1°C | Controlled temperature range for ASTM D3985 testing |
| Controlled RH Testing Ranges | 0.015 or 1% | Controlled RH capability for conditioning |
| Relative Humidity (Films) | 0% to 90% RH ± 2% | Films – carrier and test gas control |
| Relative Humidity (Packages) | Ambient or controlled by chamber | Package testing – ambient or chamber controlled |
| Sample & System | ||
| Sample Size | 50 cm² (standard), adapters for smaller sizes | Standard test area, flexible for various samples |
| Test Area | 50 cm² (standard), 5–100 cm² (with adapters) | Accommodates a wide range of sample sizes |
| Test Gases | Oxygen, Nitrogen (carrier), optional CO₂ | Flexible for different test protocols |
| Features & Benefits | ||
| Sensor Technology | eMetric™ coulometric sensor (Faraday’s Law) | Measures oxygen transmission with ASTM D3985 conformance |
| Multi-Cell Capability | Expandable up to 32 cells | Parallel testing for high throughput |
| Validation | Automated, NIST-traceable validation | Ensures accuracy and compliance |
| Operating System | Windows® 10/11, network ready | Remote access, data export, LIMS compatible |
| Operation | Fully automatic, intuitive interface | Minimal training required |
| Software Compliance | 21 CFR Part 11 ready, audit trail, user management | Meets pharmaceutical regulatory requirements |
Where OTR Testing Matters
The Systech 8101e enables precise oxygen barrier analysis for food, pharma, electronics, and advanced packaging.
Flexible Packaging Films
Oxygen barrier testing for snacks, dry foods, and medical packaging films.
High-Barrier Coatings
Testing AlOx, SiOx, EVOH, and metallized films for ultra-low OTR applications.
Sustainable Packaging
OTR testing of biodegradable polymers, PLA, and compostable packaging for eco-friendly solutions.
Medical Devices
Sterile barrier OTR testing for medical device packaging, Tyvek pouches, and healthcare products.
R&D & New Materials
Development and qualification of new oxygen barrier materials and coatings.
When you're qualifying packaging for Nestlé R&D Centre or other global brands, there's no room for error. The Systech 8101e delivers the absolute accuracy and repeatability our clients demand. MOCON and others simply couldn't match our precision requirements.
The Cost of Inadequate OTR Testing
Key facts that matter for accurate oxygen barrier validation and reliable OTR decisions
Incorrect OTR data can lead to oxygen ingress and reduced shelf life. Systech 8101e with the eMetric™ coulometric sensor covers 0.05 to 432,000 cc/(m²·day) to support both ultra-low and high OTR applications.
OTR depends strongly on temperature and humidity. Automatic relative humidity and temperature control, plus the Test Condition Matrix (TCM™), lets you test a sample at up to ten different conditions.
Working with Nestlé or global brands? They demand calibration-free accuracy and uptime. Systech 8101e delivers where MOCON and others fail. Expandable to 32 cells, Auto-Stop™ protection, and the reliability that Nestlé R&D Centre trusts in their labs.
Frequently Asked Questions
Common questions about the Systech 8101e OTR Analyzer
What is the Systech 8101e OxySense OTR Analyzer?
The Systech 8101e OxySense is a high-precision oxygen transmission rate (OTR) analyzer using eMetric coulometric sensor technology. It measures oxygen permeability with an ultra-wide range of 0.05 to 432,000 cc/m²/day, covering everything from ultra-high barrier films (0.05 = metallized films, AlOx coatings) to breathable packaging (432,000 = high transmission films). This massive range eliminates the need for multiple instruments.
Which OTR standards does the 8101e comply with?
The Systech 8101e OxySense complies with ASTM D3985, ASTM F1307, ISO 15105-2, DIN 53380-3, and JIS K7126 for oxygen transmission rate testing.
Does Nestlé use the Systech 8101e OTR Analyzer?
Yes. Nestlé R&D Centre relies on Systech OTR analyzers for their packaging qualification and testing. Proven suppliers like Uflex Jammu use Systech to meet Nestlé's strict requirements. The eMetric™ coulometric technology delivers the absolute accuracy and calibration-free operation that global food leaders demand. If you're a packaging supplier looking to work with Nestlé, using the same testing equipment they trust is your best path to qualification.
Why do suppliers to Nestlé choose Systech over MOCON?
MOCON instruments often require calibration films and have limited measurement ranges. The Systech 8101e offers zero calibration requirements with its eMetric™ sensor, plus a massive 0.05 to 432,000 cc/m²/day range (covering ultra-high barrier films at 0.05 to breathable packaging at 432,000) and Auto-Stop™ protection. When qualifying packaging for Nestlé or similar global brands, you cannot afford calibration downtime or questionable accuracy. Systech delivers superior results where others fail.
Systech vs. Labthink / GBPI / ExtraSolution – Which is best for Nestlé suppliers?
Consider the long-term value carefully. While Labthink, GBPI, and ExtraSolution offer lower-cost entry options, they typically require standard films for calibration, have segmented ranges, and may lack the absolute precision of Systech's eMetric™ technology. Nestlé R&D Centre uses Systech and their suppliers like Uflex Jammu have proven its reliability. If you want to work with them or other top-tier brands, invest in the same equipment they trust. The hidden costs of calibration downtime and failed audits far exceed any upfront savings.
Where can I buy the Systech 8101e OTR Analyzer in India?
FITCO India (Federal India Trading Company) is the authorized distributor for Systech Illinois and Industrial Physics OTR analyzers in India. We provide sales, installation, and service support across India.
The OTR Analyzer Trusted by Nestlé R&D Centre
Systech 8101e Oxygen Transmission Rate Analyzer is the choice of Nestlé R&D Centre and leading packaging suppliers like Uflex Jammu worldwide. Unmatched range: 0.05 to 432,000 cc/m²/day tests ultra-high barrier films (metallized, AlOx coatings at 0.05) to breathable packaging (432,000) in one instrument. Delivers superior results where MOCON, Labthink, GBPI, and ExtraSolution fall short with zero calibration and absolute ASTM D3985 compliance. Make the smart choice for long-term reliability when working with global brands.
