Model G28-12-PCR

  • Compatible with ISO 13503-2:2006
  • For use with frac sand, resin coated sand and ceramic proppant

Wabash MPI is proud to introduce Model G28-12-PCR proppant Crush Test press. This Genesis Series press meets the critical demands of ISO 13503-2:2006 with unsurpassed cycle repeatability. The proportional hydraulic system is capable of applying a constant rate of 13.8 MPa/min. (2000 PSI min.) from 2 ton to 28 ton clamp force within a ±2.5% deviation. The operator interface allows easy setup of press control parameters and includes ample recipe storage.

Need help selecting the right model?Share your material, standard, capacity range, and application. FITCO will help match the right testing system.
Request guidance+91 7016547709
Category:

Description

Specifications of Proppant Crush Test Press:

  • Compression force: 2-28 ton
  • Minimum 1,275 psi on a 2″ diameter crush die
  • Maximum 17,800 psi on a 2″ diameter crush die
  • Hardened plates: 12” L-R x 12” F-B fully guided platens to ensure parallelism
  • Positive stop on platens for centering the crush die
  • Open daylight: 6”-12”
  • Cylinder stroke: 6”
  • Self-contained hydraulic system
  • Available with and without 2” ID crush die (compatible with ISO 13503-2)
  • “Mini” ViewPoint control system including:
  • Allen Bradley programmable controller
  • PanelView Touch screen interface
  • Closed-loop control of clamp pressure
  • Real time graphical display of process parameters
  • Recipe storage (up to 30 recipes of 24 segments)
  • Two hand close buttons
  • Polycarbonate safety guards around the clamp area with manual sliding interlocked operator gate
  • Dimensions: 46” w x 35” d x 74” h
  • Weight: 1,900 lbs

Model G40-12-PCR

Genesis Model G28-12-PCR Proppant Crush Test Press, frac sand crush test press.

  • Compatible with ISO 13503-2:2006
  • For use with frac sand, resin coated sand and ceramic proppant

Wabash MPI is proud to introduce Model G28-12-PCR proppant Crush Test press. This Genesis Series press meets the critical demands of ISO 13503-2:2006 with unsurpassed cycle repeatability. The proportional hydraulic system is capable of applying a constant rate of 13.8 MPa/min. (2000 PSI min.) from 2 ton to 28 ton clamp force within a ±2.5% deviation. The operator interface allows easy setup of press control parameters and includes ample recipe storage.

Specifications of Proppant Crush Test Press:

  • Compression force: 2-40 ton
  • Minimum 1,275 psi on a 2″ diameter crush die
  • Maximum 25,000 psi on a 2″ diameter crush die
  • Hardened plates: 12” L-R x 12” F-B fully guided platens to ensure parallelism
  • Positive stop on platens for centering the crush die
  • Open daylight: 6”-12”
  • Cylinder stroke: 6”
  • Self-contained hydraulic system
  • Available with and without 2” ID crush die (compatible with ISO 13503-2)
  • “Mini” ViewPoint control system including:
  • Allen Bradley programmable controller
  • PanelView Touch screen interface
  • Closed-loop control of clamp pressure
  • Real time graphical display of process parameters
  • Recipe storage (up to 30 recipes of 24 segments)
  • Two hand close buttons
  • Polycarbonate safety guards around the clamp area with manual sliding interlocked operator gate
  • Dimensions: 46” w x 35” d x 74” h
  • Weight: 2,400 lbs
