Water vapor permeation analyzer Lyssy L80-5000



Modular systems for precision water vapor permeabilty testing of packaging film barriers.

The 7000 water vapor analyzer range utilises the sensitive and stable P2O5 sensor for absolute moisture measurement. These water vapor analyzers offer a wide measurement range of 0.002-1000 g/m²/day and precision temperature, humidity and flow control. Providing accurate and repeatable results for research and development testing of water transmission rate (wvtr) in both current and newly formulated packaging film materials and fast testing for Quality Control.

All Systech Illinois analyzers are certified traceable to NIST. In addition, analytical performance is validated using NIST certified gases and NIST traceable films. A set of validation films and a spare P2O5 sensor comes as standard with all of our water vapor permeation analyzers.


  • Films
  • Barriers on SiOx substrate
  • Metallized packaging foils
  • Impermeable fabrics
  • Surgical and hygienic membrance
  • PUR-coated farbrics for nursing
  • Roofing felt and roofing water vapour barrier
  • Stable fibre coatings and coated papers

    Additional information




    Water Vapor



    Measurement range

    7001 Unmasked 0.002 – 10 g/m2/day, Masked 0.02 – 70 g/m2/day,
    7002 Unmasked 0.002 – 70 g/m2/day, Masked 0.02 – 1000 g/m2/day

    Test temperature range

    5 to 50°C (41 to 122°F)

    Test RH range

    20 to 90% RH


    533 x 533 x 305 (mm)


    23.6 kg

    • Easy to use operator interface
    • Simple to operate due to the high degree of automation
    • Fast and accurate test results
    • Broad testing range covering low and high permeability
    • Automatic equilibrium detection
    • Automatic temperature control
    • Easy set-up of test parameters and sample data
    • Complete traceability in test documentation, data logging and error reports
    • Easy to use test sample holders
    • RS232 interface for communication with PC
    • Built-in printer
    • Low degree of maintenance
